Description:

E-link LNK-10G SFP+ ER Small Form Factor 10Gb/s (SFP+) transceivers are compliant with the current SFP+ Multi-Source Agreement (MSA) Specification. The high performance cooled  1270～1450nm CWDM DFB transmitter and high sensitivity PIN receiver provide superior performance for Ethernet applications up to 40km optical links. The SFP+ Module compliants with SFF-8431, SFF-8432 and IEEE 802.3ae 10GBASE-ER. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472.

Features:

►Support multi protocol from 9.95Gb/s to 11.3Gb/s

►Hot pluggable SFP+ footprint

►Compliant with SFF 8472 and IEE802.3ae

►1270～1450nm CWDM DFB transmitter

►PIN Receiver

►Duplex LC connector

►2-wire interface for management and diagnostic monitor

►Single Power 3.3V supply voltages

►Temperature range -5°C to 70°C

►Power dissipation: <1.5W

►RoHS Compliant Part

Applications:

►10GBASE-ER/EW Ethernet

►10G Fiber channel

►SONET OC-192/SDH

►CWDM Networks

E-link 10G CDWM SFP+ transceiver is specifically designed for the high performance integrated duplex data transmission over single mode optical fiber. This transceiver module is compliant with Enhanced Small Form Factor Pluggable Module SFP+ Multisource Agreement (SFF-8431).This transceiver type is specifically optimized for transport of serial data at 10.3125Gbps.
SDH STM I-64.1 at 9.953Gbps
►10GBASE-ER/EW 10G Ethernet
►1200-SM-LL-L 10G Fibre Channel
►10GE over G.709 at 11.09Gbps
►OC192 over FEC at 10.709Gbps
►Other optical links, up to 11.1Gbps

Features
►Compliant with major switch vendors
►Distances 10 km, 40 km and 70 km
►1270nm to 1450nm CWDM EML Transmitter
►RoHS Compliant and Lead-Free
►Compatibility with Cisco, Huawei, etc
►APD Receiver

• Download FileName：E-link 10G CWDM 1270~1450nm 40km SFP+ Datasheet V1.0.pdf Size： 505KB

Order Information
