8 Ports Metal DIN-Rail Fiber Splice Box Patch Panel
Model:LNK-FSB-8 Series
► Cold-roll steel, electrostatic painting
► Suitable for different adapters: FC, SC, ST, LC …
► 2pcs cable entry/exit ports; 8pcs pigtail entry/exit ports
► Splicing module of 8 fibers inside
► Max. 8pcs adapters can be loaded
Overview
LNK-FSB-8 Series 8-Port DIN-Rail Fiber Splice Box is suitable for 8-Port SC / FC / ST Simplex Adapter, LC Duplex Adapter, and it is available for the distribution and terminal connection for various kinds of optical fiber system, especially suitable for mini-network terminal distribution, in which the optical cables, patch cores or pigtails are connected.
Feature
► Cold-roll steel, electrostatic painting
► Suitable for different adapters: FC, SC, ST, LC …
► 2pcs cable entry/exit ports; 8pcs pigtail entry/exit ports
► Splicing module of 8 fibers inside
► Max. 8pcs adapters can be loaded
Application
Suitable for Pigtail, ribbon and bunch cable connect distribution
Used for wall-mounted applications
Used in FTTH, Telecommunications, CATV. etc
Dimension
- Download FileName：E-link LNK-FSB-8 Series 8 Ports DIN-Rail Fiber Splicing Box Datasheet V1.0.pdf Size： 1.05MB
Order Information
| Item | Description |
| LNK-FSB-8 |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (without any fiber adapters or pigtails) |
| LNK-FSB-S-8-SC |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs SC Simplex fiber adapters) |
| LNK-FSB-D-8-LC |
8-Port DIN-Rail Fiber Splice Box, with 2 x
PG11 cable glands and Wall mount kit. (installed with 8pcs LC Duplex fiber adapters) |
| LNK-FSB-S-8-FC |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs FC Simplex fiber adapters) |
| LNK-FSB-S-8-ST |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs ST Simplex fiber adapters) |
| LNK-FSB-S-8-SC-P |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs SC Simplex fiber adapters and pigtails) |
| LNK-FSB-D-8-LC-P |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs LC Duplex fiber adapters and pigtails) |
| LNK-FSB-S-8-FC-P |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs FC Simplex fiber adapters and pigtails) |
| LNK-FSB-S-8-ST-P |
8-Port DIN-Rail Fiber Splice Box, with 2 x PG11 cable glands and
Wall mount kit. (installed with 8pcs ST Simplex fiber adapters and pigtails) |
